Replacement acrylics/lenses are available for Lewmar Low and Medium Profile Hatches. New acrylics are supplied complete with a new seal pre-mounted, plus new handles and exterior friction lever cap.
Replacing your hatch acrylic is easy - simply remove the lid, unscrew the frame, and pull it apart, the old acrylic will drop out and you can reassemble with your new acrylic.
Please note that depending on the age and condition of your hatch, it is not uncommon for the Joining Inserts to break as the frame pulls apart. We recommend having a replacement to hand so you do not get caught out halfway through the job. We will happily refund any unused Joiners.
If you need assistance identifying your hatch model, please see the link below -
Guide: How to identify Lewmar Low and Medium Profile Hatches
Manual: Low and Medium Profile Hatch Disassembly and Assembly
| Size | Style | Width (Y) | Height (X) | Depth (Z) | Radius (R) | Width (Y1) | Height (X1) | Radius (R1) | Weight | Acrylic Thickness |
| 30 | Rectangular | 528 | 397 | 32 | 78 | 457 | 327 | 42.5 | 5.0kg | 12 |
| 40 | Square | 492 | 492 | 32 | 78 | 421 | 421 | 42.5 | 5.9kg | 12 |
| 44 | Square | 513 | 513 | 32 | 78 | 442 | 442 | 42.5 | 6.4kg | 12 |
| 50 | Rectangular | 578 | 448 | 32 | 78 | 507 | 377 | 42.5 | 6.3kg | 12 |
| 54 | Rectangular | 578 | 463 | 32 | 78 | 507 | 392 | 42.5 | 6.5kg | 12 |
| 60 | Square | 578 | 578 | 32 | 78 | 507 | 507 | 42.5 | 7.8kg | 12 |
| 70 | Square | 698 | 698 | 32 | 78 | 627 | 627 | 42.5 | 10.6kg | 12 |
| 77 | Square | 770 | 770 | 32 | 78 | 699 | 699 | 42.5 | 12.7kg | 12 |
